TH Series TH350.1D 350W RMS Mono Block Class D Amplifier

Adding Subs?

TH Series amplifiers were designed with over 25 years of amplifier experience to exceed your expectations. The TH350.1 is an excellent choice for any enthusiast thinking about adding a subwoofer or subwoofers to their vehicle.

350 Watts Of Audio Power

The TH350.1D is a mono block amplifier that is capable of delivering up to 350-watts RMS power into a 1Ω speaker load.

Ask an expert Find a location

Patented Class D Technology

Reduces external noise for premium sound quality.

Intelligent Surface Mount Technology

Cutting edge parts eliminate interference and resist vibrations on circuit board

Smart Engage

Patented auto turn-on circuit makes installation easy.

TH1200.1D With Top Open Shown

TH350.1 Key Features

Patented Adaptive Class D Technology
Patented Smart Engage Auto Turn On
Surface Mount Design
Dual Sided Fiberglass Printed Circuit Board
Convection Cooled Design

350 Watts Of Raw Audio Power

The TH350.1D is a mono block amplifier that is capable of delivering up to 350-watts RMS power into a 1Ω speaker load. This unit features several technologies that have been proven over time to deliver exceptional sound quality. The TH350.1D includes a patent power supply, patented Adaptive Class D design that increases sound quality by eliminating RF interference generated by the MOSFET power supply, and Smart Engage auto turn on technology that eliminates the need to run a remote wire to activate the amplifer during installation saving time and possible damage to the dashboard.

This model also features a 24dB/oct low pass filter that increases sound quality by reducing unwanted frequencies more effectively, a variable bass boost from 0-12 dB at 40Hz, and a variable subsonic filter for use in vented subwoofer enclosure applications.

WHAT OUR CUSTOMERS SAY!

Well im very picki when it comes to car audio system , in the past ive had a truck equiped mtx amps both for spkrs and subs olso had a 12" dual subwoofer box and that thing hit so hard it was unbeliabable ...not to mention my door spkrs ...i would recomend mtx products to anyone ..cant go wrong ..MTX IS THE BEST....

samuel 3/13/2013 TH1200

This amp will surprise you. This should drive any 8", just about every 10", and quite a few 12" subs well. Running a 1 ohm stable operation has this amp running barely warm to the touch hours into a play session. Plenty of features and adjustments for anything you should need, included bass control dials in bass level just right, clean sounding power output, compact and clean design, and the level of versatility this amp offers makes it hard to beat.

Matt 11/1/2013 TH350

Fine Craftmanship

The TH350.1D also incorporates Intelligent Surface Mount Design Technology which utilizes smaller parts and separates the circuit board into localized zones eliminating interference and improving sound quality. The dual layer circuit board has more copper traces than single sided boards and is able to more efficiently transfer signal across the board with less loss. A clip light is included making it easy to set the amplifier's gain control to the source unit.

Also available in 650-Watt and 1200-Watt models.

Dimensions & Details

SPECIFICATIONS

Description: Mono Block
4Ω RMS Power Output: 125W x 1 Channel
Signal to Noise Ratio: 75dB
2Ω RMS Power Output: 250W x 1 Channel
1Ω RMS Power Output: 350W x 1 Channel
Topology: Class D
THD: <1%
Frequency Response: 20Hz - 200Hz
Crossover: Variable Low @ 40Hz to 200Hz, 24dB/Oct
Subsonic Filter: 20Hz to 50Hz,12dB/Oct, Variable
Bass Boost: +12dB @ 40Hz
Max Sensitivity: 250mV
Maximum Input Signal: 5V
Height: 7.06"
Width: 10"
Depth: 2.13"
Recommended StreetWires Amp Kit: ZN5K-04 OR ZN3K-04
